Smart Aquarium

Summary of Smart Aquarium


The project displays status of a previously built smart aquarium: temperature, date/time, and sump water level shown on a color TFT. The original system controls lights and pump via Arduino Uno, Ethernet Shield, ULN2803, relays, and receptacles, plus a servo feeder. The EENG 383 addition adds a second Arduino Uno, Adafruit 1.8" 18-bit Color TFT Shield with Joystick, waterproof temperature sensor, infrared proximity sensor, and a floating platform to present real-time tank data.

Parts used in the Smart Aquarium:

  • External power supply
  • Arduino Uno (primary)
  • Ethernet Shield
  • ULN2803 driver
  • 4 120V AC relays
  • 4 controlled 120V AC receptacles
  • Servo motor feeding system
  • Arduino Uno (second)
  • Adafruit 1.8 inch 18-bit Color TFT Shield with Joystick
  • Waterproof temperature sensor
  • Infrared proximity sensor
  • Floating platform

The goal of our project is to display the status of a previously implemented smart aquarium. The previously implemented system includes an external power supply, Arduino Uno, Ethernet Shield, ULN2803 driver, 4 120V AC relays, and 4 controlled 120V AC receptacles, and a servo motor feeding system.

The four controlled receptacles supply power to three different lighting options and power to the sump pump. The EENG 383 project we implemented provides real time tank information to a full color LCD screen. The system includes a second Arduino Uno, Adafruit 1.8″ 18-bit Color TFT Shield with Joystick, waterproof temperature sensor, infrared proximity sensor, and a floating platform. The goal is to display the tank temperature, date and time, and water level in the sump pump.

Smart Aquarium PDF



Read More Detail :Smart Aquarium



Quick Solutions to Questions related to Smart Aquarium:

  • What does the project display on the screen?
    It displays tank temperature, date and time, and water level in the sump pump.
  • Which microcontrollers are used in the system?
    Two Arduino Uno boards are used: one in the original system and a second for display and sensing.
  • How is power distributed to lights and pump?
    Four controlled 120V AC receptacles, driven by 4 relays and a ULN2803 driver, supply power to three lighting options and the sump pump.
  • What display hardware is used for real time information?
    An Adafruit 1.8 inch 18-bit Color TFT Shield with Joystick is used for the full color LCD display.
  • Which sensors provide tank data?
    A waterproof temperature sensor and an infrared proximity sensor are used, along with a floating platform for water level measurement.
  • Is there an automated feeding mechanism?
    Yes, a servo motor feeding system is part of the original implementation.
  • Does the system include network capability?
    Yes, an Ethernet Shield is included in the original system.
  • What component drives the relays?
    The ULN2803 driver is used to drive the relays.
